3500 Single Hung Windows
Features
- Warm-edge spacer system maximizes energy efficiency and improves seal performance of insulated glass units
- Welded, multi-chambered frame and sash for superior strength and energy-efficiency
- Integral J-Channel and mounting fin with pre-punched holes for easy and efficient installations
- Top glass is drop-in tape glazed for easy material pass through
- Heavy-duty weatherstripping for protection against wind, rain, dust, and noise
Product Details
- Multi-chamber mainframe design
- 2-7/8” frame depth
- 3/4” insulating glass
- 4-9/16”, 6-9/16”, and 7-9/16” wood extension jambs available
- Continuous head and sill mulling for twins and triples
- Brickmould available
Performance Ratings
- STC: 28
- U-Value: 0.30-0.47
- SHGC: 0.20-0.64
- VLT: 0.39-0.66
Glass Options
- Low-E
- HP Low-E
- Tempered
- Obscure
- Rain
- Argon gas enhanced
Grid Options
- 5/8” flat grids-between-the-glass
- 3/4” flat grids-between-the-glass (Southern Region only)
- 7/8” flat grids-between-the-glass (Eastern Region only)
- 11/16” sculptured grids-between-the-glass
- 15/16” sculptured grids-between-the-glass (Eastern Region only)
- 1-1/8” simulated divided light (Southern Region only)
Hardware
- Color match
- Recessed tilt latch
- Surface-mounted tilt latch available (3500HP)
- Optional window operating control device (WOCD)
